Updates: USB 2.0 high speed (480Mb/s) interface. RS-422 Control: 1 x input for controlling router crosspoint switching. Router Configuration: Use either RJ45 Ethernet or USB 2.0 high speed interface shared over IP network.
Router Control: Use either RJ45 Ethernet or USB 2.0 high speed interface or Smart Control shared over IP network. Simultaneous routing of 2K, HD, SD video and DVB-ASI.ĭevice Control: Up to 72 bidirectional Sony compatible RS-422 deck control ports via breakout cable. Multi Rate Support: Auto detection of SD, HD or 3 Gb/s SDI. SDI Video Output: Up to 72 x SDI/HD-SDI, 3Gb/s SDI and ASI with SDI re-clocking. That's true multiple fault tolerance, unique to Universal Videohub, and eliminates any situation where a faulty crosspoint can go unnoticed and then be unavailable if the main crosspoint fails.SDI Video Input: Up to 72 x SDI/HD-SDI, 3Gb/s SDI and ASI.
In the rare event of multiple faults occurring in both cross point cards, Universal Videohub 288 automatically detects and combines the still functioning parts of both cross point cards together to keep the router running.
Universal Videohub 288 also offers true multiple fault redundancy, where different faults in both crosspoint cards can be handled. In case of failure, the cross point will instantly change over allowing continuous operation. Universal Videohub 288 even includes an extra slot for a redundant cross point and power supply. Universal Videohub has no electronic components on the motherboard and all electronics can be hot swapped with replacements in case of failure, or when upgrading. Universal Videohub is the router you need for true 24/7 reliability because its card based design lets every electronic component be easily replaced in the rare event of failure. This makes it easy to partially load SDI interface cards, to start at an affordable size, and then add more SDI interface cards over time to grow to a massive 288 x 288 size! To make scalability even easier, the cross point card and power supply cards from the Universal Videohub 72 can be plugged into the Universal Videohub 288.
#BLACKMAGIC UNIVERSAL VIDEOHUB 72 FREE#
Universal Videohub ships unpopulated, without any cards plugged in, so you are free to build your router any way you want! For example, you can plug in BNC SDI cards and optical fiber SDI cards in any combination depending on the equipment you have. With Universal Videohub, you get flexibility, quality and redundancy, all at an incredibly affordable price!
#BLACKMAGIC UNIVERSAL VIDEOHUB 72 FULL#
The larger Universal Videohub 288 model supports dual crosspoint and power supply cards for full redundancy.
#BLACKMAGIC UNIVERSAL VIDEOHUB 72 SERIAL#
Universal Videohub includes powerful features such as SD, HD and 3 Gb/s SDI auto-switching, built in deck control ports, and ethernet and serial crosspoint control. Universal Videohub comes in two models for a maximum 72 x 72 or 288 x 288 crosspoint size, and because every module in the router is card based, you can mix and match components to get the router you need, and hot swap cards in the unlikely event of failure! If you're looking for true redundancy and the ability to build your own router with both BNC SDI and optical fiber SDI, then Universal Videohub is the perfect choice. The Universal Videohub 72 rack frame is only 5 RU and 6 inches deep and can support a single 72 x 72 crosspoint card and a single power supply card.īuild your own router with Universal Videohub! Add either regular copper SDI or optical fiber SDI interface cards as you need, up to a 72 x 72 SDI size router. Universal Videohub 72 is a fully scalable 3G/HD/SD and deck control routing switcher. Compatible with Universal Videohub 72 and 288 frames. Universal Videohub 72 Crosspoint Card Supports up to 72 x 72 SDI and control, ethernet and serial router control, genlock and alarm indictors.
